Two Piece High Platform Flanged Ball Valve

Zhejiang Bolaisi Valve Co., Ltd. is an experienced industrial valve supplier with a complete production, machining, inspection, and quality control system.The company strictly follows manufacturing and quality standards, adopting advanced production technologies and precision equipment. Every valve like Two Piece High Platform Flanged Ball Valve undergoes multiple processes including machining, assembly, pressure testing, and final inspection before shipment, ensuring stable performance and reliable quality for industrial applications.

Actual Working Condition Performance Testing

Multi-Scenario Pipeline Application Tests

Testing Applications:

· Chemical processing pipelines

· Municipal water supply and drainage systems

· Gas transmission pipelines

· Power plant HVAC and heating pipelines

Compatible Media:

· Clean water

· Oil products

· Natural gas

· High-temperature steam

· Slightly corrosive fluids

Test Conclusion:

For industrial shut-off valves, sealing reliability and automation compatibility are the key performance requirements. The core design objectives of this Two Piece High Platform Flanged Ball Valve are low flow resistance, fast opening and closing operation, and stable sealing performance under different operating conditions.

Floating Ball Sealing Structure Performance Comparison

Conventional Two-Piece Flanged Ball Valve

· Valve stem leakage may occur after long-term exposure to high-temperature media.

· Without a standardized mounting platform, additional brackets are required for actuator installation.

· Maintenance and replacement operations are relatively complicated.

Bolaisi Two-Piece High Platform Ball Valve

· Gland-type valve stem packing structure provides extremely low leakage performance.

· Sealing performance remains stable after high and low temperature cycle testing.

· ISO5211 high platform enables direct installation of electric or pneumatic actuators.

· Convenient on-site maintenance and easier equipment integration.

Key Structural Design Advantages

Two-Piece Split Valve Body

The two-section valve body features high casting accuracy and consistent machining dimensions. The split structure allows easier inspection and maintenance without removing the entire pipeline system.

Gland-Type Valve Stem Packing Seal

Multi-layer packing compression effectively prevents external leakage along the valve stem. The packing can be replaced separately during maintenance, reducing downtime and service costs.

ISO5211 Standard High Mounting Platform

The integrated high platform design provides accurate positioning and allows direct mounting of pneumatic or electric actuators without additional adapter brackets.

Floating Ball Double-Directional Sealing

The floating ball design supports bidirectional pressure sealing. The medium pressure automatically pushes the ball against the valve seat, ensuring stable sealing performance.

Temperature and Media Sealing Performance Tests

The valve has been tested under two typical operating conditions: normal-temperature fluids and high-temperature steam environments.

Soft Seal (PTFE Seat) Testing

Testing Conditions:

· Temperature: ≤150℃

· Continuous circulation testing with water, gas, and oil

Test Results:

· No obvious seat wear

· Zero leakage during air pressure testing

· Suitable for clean water, gas, and normal-temperature oil applications

Metal Hard Seal Testing

Testing Conditions:

· Temperature: ≤280℃

· Continuous operation with high-temperature steam and slightly particle-containing media

Test Results:

· Excellent resistance to high-temperature erosion

· Strong wear resistance and particle impact resistance

· No internal or external leakage under high-temperature conditions

The dual sealing design allows this Two Piece High Platform Flanged Ball Valve to cover a wide range of industrial fluid applications. Users can select suitable sealing materials according to actual working conditions, reducing inventory costs while improving equipment adaptability.

Application Areas

Municipal Water Supply and Drainage

Suitable for:

· Urban water supply networks

· Secondary water supply systems

· Wastewater shut-off pipelines

The valve can be equipped with actuators for remote water flow control.

Chemical Processing Pipelines

Suitable for:

· Oil products

· Weakly corrosive liquids

· High-temperature steam pipelines

The metal hard seal version provides excellent resistance to heat and particle erosion.

Gas Pipeline Stations

Suitable for:

· Residential gas transmission pipelines

· Gas station front-end shut-off systems

The double-direction sealing structure helps prevent gas leakage.

Power Plant Heating and Boiler Systems

Suitable for:

· Boiler steam pipelines

· Heating circulation systems

Compatible with pneumatic and electric actuators for remote operation.

Equipment Supporting Applications

Suitable for:

· Cooling circulation systems

· Oil transportation systems

Soft and hard sealing options can be selected according to different media requirements.

Factory HVAC and Heat Transfer Oil Systems

Suitable for:

· Workshop cooling water pipelines

· Heat transfer oil circulation systems

The split valve body design simplifies maintenance and replacement.

Product Selection Parameters

Product Advantages

Tested Performance with Reliable Data

All sealing performance, high-temperature resistance, and actuator compatibility tests are based on actual pipeline operating simulations, ensuring reliable product parameters.

Dual Sealing Options for Multiple Working Conditions

The soft seal version is suitable for clean and normal-temperature media, while the metal hard seal version supports high-temperature steam and particle-containing fluids up to 280℃.

ISO5211 High Platform for Easy Automation

The integrated ISO5211 mounting platform allows quick installation of electric and pneumatic actuators without additional adapters, enabling automated pipeline control.

Gland-Type Valve Stem Design for Lower Maintenance Cost

The replaceable valve stem packing reduces maintenance time and avoids unnecessary pipeline disassembly.

Wide Size Range and National Standard Compatibility

Available from DN15 to DN200, with compatibility for different national standard flange requirements.

Strict Factory Inspection for Stable Quality

Each valve undergoes machining inspection, assembly verification, and pressure testing before delivery to minimize leakage risks.

Why Choose Zhejiang Bolaisi Valve Co., Ltd.

Looking for a reliable flanged ball valve that supports high and low temperature applications, actuator installation, and convenient maintenance?

Choose the Bolaisi Two Piece High Platform Flanged Ball Valve.

With mature stainless steel valve manufacturing technology, multi-condition pipeline testing, and complete quality control procedures, Bolaisi provides stable industrial valve solutions for various fluid control applications.

As a professional valve manufacturer, the company integrates valve body production and sealing component supply, offering complete DN15-DN200 product solutions for industrial pipelines.

From reliable shut-off performance to easier maintenance and automation integration, Bolaisi helps customers achieve safer, more efficient, and more stable pipeline control.
